Yamaha ttr230 User Manual

CARB
CARBURETOR
CHAPTER 5.
CARBURATION
CARBURETOR . .............................................................................................. 5-1
REMOVAL ....................................................................................................... 5-2
DISMOUNTING .............................................................................................. 5-3
INSPECTION ................................................................................................... 5-5
MOUNTING .................................................................................................... 5-7
INSTALLATION .............................................................................................. 5-9
FUEL LEVEL ADJUSTEMENT ..................................................................... 5-10

Yamaha ttr230 Specifications

General

Engine Type	223cc air-cooled SOHC 4-stroke; 2 valves
Bore x Stroke	70.0mm x 58.0mm
Compression Ratio	9.5:1
Ignition	CDI
Transmission	Constant-mesh 6-speed; multiplate wet clutch
Final Drive	Chain
Rear Suspension	Single shock; 8.7-in travel
Front Tire	80/100-21
Rear Tire	100/100-18
Length	81.3 in
Width	31.5 in
Seat Height	34.3 in
Wheelbase	54.5 in
Ground Clearance	11.6 in
Front Suspension	Telescopic fork
Rear Brake	Drum
