FRAME
REAR WHEEL
6-28
2. Adjust:
• Transmission chain free play
Axle nut:
80 N.m (8.0 kgf.m; 57.9 ft.lb)
NOTE:
Do not loosen the axle nut after applying
torque. If the nut hole is not aligned with
the axle hole, tighten the nut until the holes
are aligned.
See Section "TRANSMISSION CHAIN FREE
PLAY ADJUSTMENT," CHAPTER 3.
3. Tighten:
• Axle nut
Transmission chain free play:
45 ~ 60 mm
Lithium-based grease
INSTALLATION
Reverse the "REMOVAL" procedure.
1. Lubricate:
• Axle
• Bearings
• Retainer lips

Yamaha ttr230 Specifications

General

Engine Type	223cc air-cooled SOHC 4-stroke; 2 valves
Bore x Stroke	70.0mm x 58.0mm
Compression Ratio	9.5:1
Ignition	CDI
Transmission	Constant-mesh 6-speed; multiplate wet clutch
Final Drive	Chain
Rear Suspension	Single shock; 8.7-in travel
Front Tire	80/100-21
Rear Tire	100/100-18
Length	81.3 in
Width	31.5 in
Seat Height	34.3 in
Wheelbase	54.5 in
Ground Clearance	11.6 in
Front Suspension	Telescopic fork
Rear Brake	Drum
