ELECT
SWITCH CHECKS
7-3
SWITCH CHECKS
In this example:
“L/B” and “L/Y” and “R” and “Br/L” have
continuity at switch “ON” position.
This manual contains the connection tables
as shown to the left. The switch terminal
connections are shown.
The column to the left indicates the switch
position, and the upper row indicates the
colors of the wires connected to the switch
terminals.
“O - O“ indicates the terminals between
which there is electrical continuity.
UNDERSTANDING THE SWITCH
CONNECTIONS
Check the switches for continuity between
terminals.
Read the following text in order to check
the switches properly.
Br/L R L/B L/Y
LOCK
OFF
ON

Yamaha ttr230 Specifications

General

Engine Type	223cc air-cooled SOHC 4-stroke; 2 valves
Bore x Stroke	70.0mm x 58.0mm
Compression Ratio	9.5:1
Ignition	CDI
Transmission	Constant-mesh 6-speed; multiplate wet clutch
Final Drive	Chain
Rear Suspension	Single shock; 8.7-in travel
Front Tire	80/100-21
Rear Tire	100/100-18
Length	81.3 in
Width	31.5 in
Seat Height	34.3 in
Wheelbase	54.5 in
Ground Clearance	11.6 in
Front Suspension	Telescopic fork
Rear Brake	Drum
