FRAME
NOTE:
Before removing the transmission chain and
gears, measure the transmission chain free
play.
6-64
TRANSMISSION RATIO
NOTE:
Loosen the screw (pinion gear) while
actuating the rear brake.
4. Remove:
• Screws 1 (pinion gear)
• Pinion gear fastener 2
• Pinion gear 3
3. Loosen:
• Transmission chain
2. Remove:
• Shift lever 1
• Pinion gear cover 3
Support the motorcycle firmly preventing
it from falling.
REMOVAL
1. Lift the rear wheel placing a support under
the engine.
VV
VV
V
WARNING
3
2
1
2
3
1
