Yamaha ttr230 User Manual

FRAME
FRONT FORK
6-29
1
2
3
4
5
6
8
9
Plastic belt
Dust cover
Tie wrap
Front fork (RH)
Cover
Lock ring
Handle-bars board
Handle-bars board
O-ring
Fork spring
Piston spring
Damper stem
Return spring
Internal tube
Oil retainer
Dust protector
Lock ring
Retainer
Spacer
Guide bushing
External tube
10
11
12
13
14
15
16
17
18
19
20
21
22
23 Front fork (LH)
E Cut the plastic belt
FRONT FORK
A
Oil capacity (each fork)
352 cm
3
From the top of the internal tube
totally compressed without spring.
B
Spring minimal free length
614.2 mm
C
Oil level (each
fork)
161 mm
From the top of
the internal tube
totally compressed
without spring.
20N.m (2.0 Kgf.m ; 14 ft.lb)
23N.m
(2.3Kgf.m
; 17 ft.lb)
20N.m
(2.0Kgf.m ; 14
ft.lb)
D USE A NEW ONE

Yamaha ttr230 Specifications

General

Engine Type	223cc air-cooled SOHC 4-stroke; 2 valves
Bore x Stroke	70.0mm x 58.0mm
Compression Ratio	9.5:1
Ignition	CDI
Transmission	Constant-mesh 6-speed; multiplate wet clutch
Final Drive	Chain
Rear Suspension	Single shock; 8.7-in travel
Front Tire	80/100-21
Rear Tire	100/100-18
Length	81.3 in
Width	31.5 in
Seat Height	34.3 in
Wheelbase	54.5 in
Ground Clearance	11.6 in
Front Suspension	Telescopic fork
Rear Brake	Drum
