SPEC
LUBRICATION POINTS AND LUBRICANT TYPES
2-19
FRAME
Speedometer
Retainer lips (all)
Wheel axle (front and rear)
Rear wheel hub
Brake shoe plate, shaft and pin
Bushes (balance) and covers
Spacer (balance)
Pivot shaft (balance)
Bush (shock absorber)
Cap (Shock absorber and relay arm)
Bush (relay arm and union arm)
Bush (relay arm and union arm)
Bush (union arm and frame)
Spacer (union arm and frame)
Bushes (relay arm and frame) and cover
Spacers (relay arm and balance)
Articulated points (brake pedal shaft and frame)
Balls and raceways (steering bearing)
Guide tube (accelerator grip)
Articulated points (brake and clutch levers)
Articulated points (side stand)
Bushes (chain tensioner)
Symbol Lubrication points

Yamaha ttr230 Specifications

General

Engine Type	223cc air-cooled SOHC 4-stroke; 2 valves
Bore x Stroke	70.0mm x 58.0mm
Compression Ratio	9.5:1
Ignition	CDI
Transmission	Constant-mesh 6-speed; multiplate wet clutch
Final Drive	Chain
Rear Suspension	Single shock; 8.7-in travel
Front Tire	80/100-21
Rear Tire	100/100-18
Length	81.3 in
Width	31.5 in
Seat Height	34.3 in
Wheelbase	54.5 in
Ground Clearance	11.6 in
Front Suspension	Telescopic fork
Rear Brake	Drum
