Yamaha ttr230 User Manual

ELECT
ELECTRIC CIRCUIT DIAGRAM - TTR230
7-1
ELECTRIC
ELECTRIC CIRCUIT DIAGRAM - TTR230
Magnet
Starter motor
Rectifier/Regulator
Starting relay
“START” switch
“ENGINE STOP” switch
1
2
3
4
5
6
7
Main fuse
Main switch
Neutral switch
Clutch switch
C.D.I. unit
Ignition coil
Spark plug
8
9
10
11
12
13
14
WhiteW
BlackB
RedR
GreenG
Blue/YellowLY
Orange
Light blueSb
Br
YellowY
Black/WhiteBW
Black/YellowBY
Brown/WhiteBrW
Blue/WhiteLW
Blue/YellowLY
Red/WhiteRW
O
Brown
Red/BlackRB
BlueL
1
2
3
5
6
7
8
9
0
A
B
C
D
W
R
B
GLY
B
R
B
LW
B
O
B
B
Br
Br
B
B
4
LY
L
B
RB
RB
RBr
RB
Br

Yamaha ttr230 Specifications

General

Engine Type	223cc air-cooled SOHC 4-stroke; 2 valves
Bore x Stroke	70.0mm x 58.0mm
Compression Ratio	9.5:1
Ignition	CDI
Transmission	Constant-mesh 6-speed; multiplate wet clutch
Final Drive	Chain
Rear Suspension	Single shock; 8.7-in travel
Front Tire	80/100-21
Rear Tire	100/100-18
Length	81.3 in
Width	31.5 in
Seat Height	34.3 in
Wheelbase	54.5 in
Ground Clearance	11.6 in
Front Suspension	Telescopic fork
Rear Brake	Drum
