FRAME
2. Measure:
• Spring free length a
Out of specification = > Replace
3. Check:
• Damper stem 1
Wear/warping/damage => Replace.
Contamination = > Blow all passages
with compressed air.
• Stem ring 2
FRONT FORK
6-34
2
1
1
2
INSPECTION
VV
VV
V
WARNING
Do not try to straighten out the damper
stem, since this may impair the tube.
VV
VV
V
WARNING
Do not try to straighten out the internal
tube, since it may be impaired.
1. Check:
• Internal tube 1
• External tube 2
Scratches/warping/damage => Replace.
4. Check:
• Return spring 1
Damage = > Replace.
5. Check:
• Oil retainer 1
• O-ring 2
Damage = > Replace.
1
2
1
Spring free length a :
614.2 mm
