Yamaha ttr230 User Manual

ELECT
ELECTRIC CIRCUIT DIAGRAM TTR230 ............................................... 7-1
COLOR CODE........................................................................... 7-1
ELECTRIC COMPONENTS. ......................................................... 7-2
SWITCH CHECKS ............................................................................ 7-3
UNDERSTANDING THE SWITCH CONNECTIONS ......................... 7-3
CHECKING THE SWITCH CONNECTIONS .................................... 7-4
IGNITION SYSTEM ........................................................................... 7-6
IGNITION CIRCUIT OPERATION ................................................. 7-6
TROUBLESHOOTING ................................................................ 7-7
ELECTRIC STARTING SYSTEM ........................................................ 7-13
TROUBLESHOOTING .............................................................. 7-13
STARTER MOTOR .................................................................. 7-17
CHARGING SYSTEM ...................................................................... 7-24
TROUBLESHOOTING .............................................................. 7-24
CHAPTER 7.
ELECTRIC SYSTEM

Yamaha ttr230 Specifications

General

Engine Type	223cc air-cooled SOHC 4-stroke; 2 valves
Bore x Stroke	70.0mm x 58.0mm
Compression Ratio	9.5:1
Ignition	CDI
Transmission	Constant-mesh 6-speed; multiplate wet clutch
Final Drive	Chain
Rear Suspension	Single shock; 8.7-in travel
Front Tire	80/100-21
Rear Tire	100/100-18
Length	81.3 in
Width	31.5 in
Seat Height	34.3 in
Wheelbase	54.5 in
Ground Clearance	11.6 in
Front Suspension	Telescopic fork
Rear Brake	Drum
