Command groups
Zoom command group
Zoom commands let you expand and position the waveform display horizontally
and vertically, without changing the time base or vertical settings.
NOTE. Zoom commands are available once a view has been added.
Table 2-43:
Zoom commands
Command
Descriptio
n
DISplay:MATHFFTView<x>:ZOOM:XAXIS:
FROM
Sets or queries the start of the zoom x axis in the specified plot view.
DISplay:MATHFFTView<x>:ZOOM:XAXIS:
TO
Sets or queries the end of the zoom x axis in the specified plot view.
DISplay
:MATHFFTView<x>:ZOOM :YAXIS:
FROM
Sets or q
ueries the start of the zoom y axis in the specified plot view.
DISplay:MATHFFTView<x>:ZOOM:YAXIS:
TO
Sets or queries the end of the zoom y axis in the specified plot view.
DISplay:PLOTView<x>:ZOOM:XAXIS:FROM Sets or queries the start of the zoom x-axis in the specified plot view.
DISplay:PLOTView<x>:ZOOM:XAXIS:TO Sets or queries the end of the zoom x-axis in the specified plot view.
DISplay:PLOTView<x>:ZOOM:YAXIS:FROM Sets or queries the start of the zoom y-axis in the specified plot view.
DISplay:PLOTView<x>:ZOOM:YAXIS:TO Sets or queries the end of the zoom y-axis in the specified plot view.
DISplay:REFFFTView<x>:ZOOM:XAXIS:
FRO
M
Sets or returns the left edge of the z oom x-axis in the specified plot view.
DIS
play:REFFFTView<x>:ZOOM:XAXIS:TO
Set
s or queries the right edge of the zoom x-axis in the specified plot view.
DI
Splay:REFFFTView<x>:ZOOM:YAXIS:
FROM
Se
ts or queries the bottom value of the zoom y-axis in the specified plot view.
DISplay:REFFFTView<x>:ZOOM:YAXIS:TO Sets or queries the top value of the zoom y-axis in the specified plot view.
DISplay:WAVEView<x>:ZOOM:ZOOM<x>:
HORizontal:POSition
Sets or queries the horizontal zoom position (of the specified zoom in the specified
waveview) of the zoomed waveform or zoom waveform in the display, around which
t
he zoom waveform displays.
DISplay:WAVEView<x>:ZOOM:ZOOM<x>:
HORizontal:SCALe
Sets or queries the zoom horizontal scale factor, of the specified zoom in the
specified waveview, in which the zoom waveform is displayed.
DISplay:WAVEView<x>:ZOOM:ZOOM<x>:
HORizontal:WINSCALe
Sets or queries the zoom window horizontal scale in the specified waveview.
DISplay:WAVEView<x>:ZOOM:ZOOM<x>:
STATe
Sets or queries the specified zoom in the specified waveview on or off.
DISplay:WAVEView<x>:ZOOM:ZOOM<x>:
VERTical:POSition
Sets or queries the vertical position of the specified zoom in the specified waveview,
in which the zoom waveform is displayed.
DISplay:WAVEView<x>:ZOOM:ZOOM<x>:
VERTical:SCALe
Sets or queries the zoom vertical scale factor of the specified waveform for the
specified zoom in the specified w aveview.
DISplay:WAVEView<x>:Zoom? Queries the zoom parameters of the specified waveview.
DISplay:WAVEView<x>:ZOOM:ZOOM<x>? Queries the zoom parameters of the specified zoom in the specified waveview.
2-92 MSO54, MSO56, MSO58, MSO58LP Programmer
