Yamaha F200B Service Manual

5-9
ELEC
Electrical system
Starboard
1 Wiring harness
2 Stator assembly lead
3 Rectifier Regulator lead
4 Power supply lead
5 Isolator lead
6 Ground lead
7 Starter motor lead
8 PTT motor lead
È Fit the stator assembly lead into the
groove in the junction box.
É Fasten the PTT motor lead and wiring har-
ness ground lead using the holder.
Ê Connect the starter motor lead and brown
lead of the wiring harness together.
A-A
E-E F-F
G-G
B-B C-C D-D
A
A
B
B
C
G
G
E E
F F
D D
C
5
5
6
Ì
Ë
Í
È
Ï
Î
É
Ñ
Ê
×
Ó
Ò
Ô
Õ
Ù
Ú
Û
3
3
3
3
3
3
8
8
7
7
7
6
6
6
5
1
1
2
2
2
2
2
2
2
1
1
4
4
4
5
6
1
1
4
5
1
4
