Yamaha F200B Service Manual

1-7
SPEC
Specification
Electrical system technical data
Ignition timing control system
Item Unit
Model
F200BET FL200BET F250GET FL250GET
Spark plug
Gap mm (in) 1.0–1.1 (0.039–0.043)
Ignition coil
Input voltage V 12.0
Pulser coil
Air gap mm (in) 1.4–1.6 (0.055–0.063)
Resistance (*1)
At 20 °C (68 °F) Ω 396.0–594.0
Output peak voltage
At cranking (unloaded) V 3.0
At cranking (loaded) V 2.7
At 1500 r/min (loaded) V 14.5
At 3500 r/min (loaded) V 17.8
Cam position sensor
Input voltage V 12.0
Knock sensor
Resistance (*1)
At 20 °C (68 °F) kΩ 504.0–616.0
Air temperature sensor
Resistance (*1)
At 20 °C (68 °F) kΩ 2.21–2.69
At 80 °C (176 °F) kΩ 0.32
Input voltage V 4.75–5.25
Neutral switch
Input voltage V 4.75–5.25
Air pressure sensor
Input voltage V 4.75–5.25
Output voltage
At –20.0 kPa (–0.20
kgf/cm
2
, –2.9 psi)
V3.21
At –46.7 kPa (–0.467
kgf/cm
2
, –6.8 psi)
V2.16
Engine temperature sensor
Resistance (*1)
At 20 °C (68 °F) kΩ 54.2–69.0
At 100 °C (212 °F) kΩ 3.12–3.48
Thermoswitch
Input voltage (*1) V 11.4
Temperature
Switch ON °C (°F) 84–90 (183–194)
Switch OFF °C (°F) 68–82 (154–180)
(*1) The figures are for reference only.
