2-2
2
Engine control system component
1 OCV (STBD)
2 Thermoswitch (STBD)
3 APS
4 Neutral switch
5 Shift cut switch
6 Fuel injector (STBD)
7 Cam position sensor (STBD IN)
8 Ignition coil (STBD)
9 Knock sensor
0 Engine ECM
A Ignition coil (PORT)
B Cam position sensor (PORT EX)
C Pulser coil
D Engine temperature sensor
E Thermoswitch (PORT)
F OCV (PORT)
G Cam position sensor (PORT IN)
H Fuel injector (PORT)
I High-pressure fuel pump
J Low-pressure fuel pump
K TPS
L Oil pressure sensor
M ETV
N Air pressure sensor
O Vapor shut-off valve
P Air temperature sensor
3
1
2
6
7
8
9
0
A
B
C
D
F
E
G
H
I
J
K
L
M
N
O
P
4
5
Electronic control system
