Yamaha F200B Service Manual

7-56
7
Exhaust cover
No. Part name Q’ty Remarks
1Bolt 28 M6 × 50 mm
2Plug 2 M18 × 17 mm
3Gasket 2 39
3939
39
4 Exhaust outer cover (PORT) 1
5Gasket 2 39
3939
39
6 Dowel 2
7 Exhaust inner cover (PORT) 1
8 Anode 2
9Screw 2 M6 × 16 mm
10 Anode 2
11 Screw 2 M4 × 12 mm
12 Gasket 1 39
3939
39
13 Exhaust outer cover (STBD) 1
14 Exhaust inner cover (STBD) 1
15 Gasket 1 39
3939
39
1
1
3
4
5
5
7
8
9
8
9
10
11
10
11
14
15
13
12
6
6 N
·
m (0.6 kgf
·
m, 4.4 ft
·
lb)
12 N
·
m (1.2 kgf
·
m, 8.9 ft
·
lb)
1
2
3 N
·
m (0.3 kgf
·
m, 2.2 ft
·
Ib)
55 N
·
m (5.5 kgf
·
m, 40.6 ft
·
Ib)
2
2
3
6
Camshaft / Exhaust cover
