Yamaha F200B - PTT Unit

1-20
1
PTT unit
Upper mounting nut
—
72 7.2 53.1
Lower mounting nut
—
72 7.2 53.1
Upper mount bracket bolt M10 54 5.4 39.8
Engine oil drain bolt M14 28 2.8 20.7
Baffle plate screw M6 4 0.4 3.0
Apron stay
—
80.85.9
Oil pan assembly bolt
M8 20 2.0 14.8
M10 42 4.2 31.0
PCV
—
80.85.9
Oil strainer bolt M6 12 1.2 8.9
Oil pan bolt M8 20 2.0 14.8
Exhaust manifold bolt M8 20 2.0 14.8
Muffler bolt M8 20 2.0 14.8
Grease nipple (clamp bracket and swivel
bracket)
—
30.32.2
Self-locking nut (through tube)
—
22 2.2 16.2
Trim sensor screw M6 4 0.4 3.0
Friction plate screw M6 4 0.4 3.0
Part to be tightened Screw size
Tightening torques
N·mkgf·mft·lb
PTT unit bolt M10 42 4.2 31.0
Reservoir cap
—
70.75.2
PTT motor bolt M8 19 1.9 14.0
Reservoir bolt M8 19 1.9 14.0
Gear pump bolt M5 7 0.7 5.2
Gear pump bracket bolt M5 7 0.7 5.2
Manual valve
—
20.21.5
Tilt ram
—
65 6.5 47.9
Tilt cylinder end screw
—
90 9.0 66.4
Tilt piston bolt
—
70.75.2
Trim cylinder end screw
—
160 16.0 118.0
Pipe joint adapter
—
20 2.0 14.8
Pipe joint
—
15 1.5 11.1
Part to be tightened Screw size
Tightening torques
N·mkgf·mft·lb
Specified tightening torque
