Yamaha F200B Service Manual

6-17
FUEL
Fuel system
Removing the intake silencer
1. Remove the flywheel magnet cover.
2. Disconnect the air temperature sensor
coupler a, and then remove the air tem-
perature sensor 1.
3. Remove the blowby hose 2.
4. Disconnect the vapor gas hose 3, and
then remove the intake silencer 4.
Removing the intake manifold
1. Remove the fuel drain hose 1 from the
intake manifold (PORT) 2.
2. Remove the intake manifolds 2 and 3.
1
a
2
4
3
2
1
PORT
3
2
