Yamaha F200B - Cooling Water Passage Cover

7-70
7
Cooling water passage cover
No. Part name Q’ty Remarks
1Hose 1
2 Plastic tie 16
3 Joint 4
4Hose 1
5Hose 1
6Hose 1
7Hose 1
8 Clamp 1
9Hose 1
10 Hose 1
11 Clamp 1
12 Joint 1
13 Holder 1
14 Hose 1
15 Holder 1
16 Holder 1
17 Bolt 1 M6 × 12 mm
19
17
16
14
20
2
27
22
23
26
2
2
24
25
21
3 N m (0.3 kgf m, 2.2 ft lb)
9
9
18
11
15
13
2
12
10
20
16
1
12 N m (1.2 kgf m, 8.9 ft lb)
32 N
·
m (3.2 kgf
·
m, 23.6 ft
·
Ib)
2
2
2
2
3
3
6
7
2
7
8
3
3
2
5
3
6
4
1
A
B
B
A
7 mm
(0.28 in)
9 mm
(0.35 in)
13 15
12 mm
(0.47 in)
12 mm
(0.47 in)
Cylinder head / Cooling water passage cover
