Yamaha F200B Service Manual

1-8
1
Fuel injection control system
Engine speed control system
Item Unit
Model
F200BET FL200BET F250GET FL250GET
Fuel line
Pressure (*1)
Within 5 seconds after
engine start switch
turned to ON
kPa
(kgf/cm
2
,
psi)
290.0 (2.90, 42.1)
At engine idle speed
kPa
(kgf/cm
2
,
psi)
260.0 (2.60, 37.7)
Fuel injector
Resistance (*1)
At 20 °C (68 °F) Ω 12.0
Low-pressure fuel pump
Resistance (*1)
At 20 °C (68 °F) Ω 0.5–4.0
High-pressure fuel pump
Resistance (*1)
At 20 °C (68 °F) Ω 0.3–10.0
Vapor shut-off valve
Resistance (*1)
At 20 °C (68 °F) Ω 30.0–34.0
Water detection switch
Input voltage V 4.75–5.25
(*1) The figures are for reference only.
Item Unit
Model
F200BET FL200BET F250GET FL250GET
Oil pressure sensor
Input voltage V 4.75–5.25
Output voltage (*1)
At 392.0 kPa (3.92
kgf/cm
2
, 56.8 psi)
V2.5
At 784.0 kPa (7.84
kgf/cm
2
, 113.7 psi)
V4.5
APS
Resistance (*1)
With accelerator lever
fully closed
APS 1 and APS 2
At 20 °C (68 °F) kΩ 0.8
With accelerator lever
fully open
APS 1 and APS 2
At 20 °C (68 °F) kΩ 5.3
Output voltage (*1)
Electrical system technical data
