Yamaha F200B Service Manual

7-46
7
Camshaft
No. Part name Q’ty Remarks
1Bolt 6 M7 × 48 mm
2Camshaft cap 1
3Camshaft cap 1
4 Dowel 6
5Bolt 26 M7 × 37 mm
6 Camshaft cap 13
7Cap 2
8Gasket 2 39
3939
39
9 VCT bolt 2 M12 × 35 mm
10 VCT assembly 2
11 Oil seal 4 39
3939
39
12 Dowel 4
13 Camshaft (PORT IN) 1
14 Bolt 2 M10 × 35 mm
15 Driven sprocket 2
16 Camshaft (PORT EX) 1
17 Valve lifter 24
32 N m (3.2 kgf m, 23.6 ft lb)
60 N m (6.0 kgf m, 44.3 ft lb)
60 N m (6.0 kgf m, 44.3 ft lb)
1
2
8 N m (0.8 kgf m, 5.9 ft lb)
17 N
m (1.7 kgf m, 12.5 ft lb)
1
2
8 N m (0.8 kgf m, 5.9 ft lb)
17 N
m (1.7 kgf m, 12.5 ft lb)
8 N m (0.8 kgf m, 5.9 ft lb)
17 N
m (1.7 kgf m, 12.5 ft lb)
1
2
7
8
10
10
11
12
18
20
4
21
21
6
6
1
5
15
14
6
6
5
5
22
17
17
17
12
16
7
8
9
10
11
11
12
13
12
15
14
11
19
2
4
4
3
17
9
Cylinder head cover / Camshaft
