Yamaha F200B Service Manual

1-9
SPEC
Specification
VCT system
PTT system
With remote control lever
fully closed
APS 1 V 0.550–0.850
APS 2 V 0.400–1.000
With remote control lever
fully open
APS 1 and APS 2 V Above 3.250
TPS
Output voltage (*1)
With throttle valve fully
closed
TPS 1 V 0.500–0.700
With throttle valve fully
open
TPS 2 V 4.600–4.700
Shift cut switch
Input voltage V 4.75–5.25
(*1) The figures are for reference only.
Item Unit
Model
F200BET FL200BET F250GET FL250GET
OCV
Resistance (*1)
At 20 °C (68 °F) Ω 6.7–7.7
Input voltage V 12.0
(*1) The figures are for reference only.
Item Unit
Model
F200BET FL200BET F250GET FL250GET
Trim sensor
Free position resistance (*1)
At 20 °C (68 °F) Ω 247.6–387.6
Setting resistance Ω 9.0–11.0
(*1) The figures are for reference only.
Item Unit
Model
F200BET FL200BET F250GET FL250GET
