6-18
6
3. Remove the blowby hose 4.
Checking the intake manifold
1. Check the intake manifolds. Replace if
cracked or deformed.
2. Check the intake silencer. Replace if
cracked or deformed.
3. Check the blowby hoses. Replace if
cracked or damaged.
Checking the air temperature sensor
1. Check the air temperature sensor. See
“Checking the air temperature sensor”
(5-56).
Installing the intake manifold
Do not reuse a gasket, always replace it
with a new one.
1. Connect the blowby hose 1 with the
paint mark a facing outward, and then
fasten it using the holder 2.
2. Install new gaskets onto the intake mani-
folds. Make sure to fit the protrusion on
each gasket into its corresponding slot in
the intake manifolds.
TIP:
Make sure that the tab on the gaskets is
properly and firmly fitted into the slot in the
intake manifolds.
3. Install the intake manifolds 3 and 4
temporarily.
4
1
2
a
PORTSTBD
Intake manifold
To Next Page
