Yamaha F200B Service Manual

6-11
FUEL
Fuel system
Fuel filter assembly
No. Part name Q’ty Remarks
1Hose 1
2 Plastic tie 6
3Bracket 1
4Bolt 2 M6 × 25 mm
5Grommet 2
6 Collar 2
7Bolt 2 M6 × 14 mm
8 Fuel filter assembly 1
9O-ring 1 39
3939
39
10 Fuel filter element 1
11 Clip 1
12 Float 1
13 Fuel cup assembly 1
14 Hose 1
15 Holder 1
16 Joint 2
17 Hose 1
9 mm
(0.35 in)
12 mm
(0.47 in)
15 18
12 mm
(0.47 in)
12 mm
(0.47 in)
1
2
2
2
2
2
8
9
10
11
12
13
14
16
16
2
17
15
18
5 N m (0.5 kgf m, 3.7 ft lb)
3
4
5
6
7
