Yamaha F200B - Power Unit Assembly

7-6
7
Power unit assembly
No. Part name Q’ty Remarks
1 Power unit 1
2Gasket 1 39
3939
39
3 Dowel 2
4Bolt 2 M6 × 20 mm
5 Cable holder 1
6Bolt 2 M6 × 30 mm
7 Retaining plate 1
8 Rigging tube retainer 1
9 Plastic tie 1
10 Rigging grommet 1
11 Bolt 7 M10 × 35 mm
12 Bolt 6 M10 × 140 mm
13 Nut 2
14 Apron (PORT) 1
15 Bolt 1 M6 × 30 mm
16 Bolt 7 M6 × 14 mm
17 Grommet 6
7
6
21
22
13
17
17
14
19
16
20
16
16
15
18
16
2
3
3
11
11
12
1
25
25
26
24
1111
12
12
12
3
3
23
4 N m (0.4 kgf m, 3.0 ft lb)
10
9
4
5
8
42 N m (4.2 kgf m, 31.0 ft lb)
28
27 28
11
Power unit (check and adjustment) / Power unit assembly
