Cisco NCS 2000 series Troubleshoot Manual

Laser radiation presents an invisible hazard, so personnel should avoid exposure to the laser beam.
Personnel must be qualified in laser safety procedures and must use proper eye protection before
working on this equipment. Statement 300
Warning
SFP, SFP+, and XFP modules must be matched on both ends by type: SX to SX, LX to LX, or ZX to ZX.
Note
Remove SFP or XFP Connectors
Before you begin
Invisible laser radiation may be emitted from disconnected fibers or connectors. Do not stare into beams
or view directly with optical instruments. Statement 1051.
Warning
SUMMARY STEPS
1. Disconnect the network fiber cable from the SFP or XFP LC duplex connector.
2. Release the SFP or XFP from the slot by simultaneously squeezing the two plastic tabs on each side.
3. Slide the SFP out of the card slot. A flap closes over the SFP slot to protect the connector on the card.
DETAILED STEPS
Step 1 Disconnect the network fiber cable from the SFP or XFP LC duplex connector.
Step 2 Release the SFP or XFP from the slot by simultaneously squeezing the two plastic tabs on each side.
Step 3 Slide the SFP out of the card slot. A flap closes over the SFP slot to protect the connector on the card.
Install an SFP, SFP+, or XFP Connector
Before you begin
Invisible laser radiation could be emitted from the end of the unterminated fiber cable or connector.
Do not stare into the beam directly with optical instruments. Viewing the laser output with certain
optical instruments (for example, eye loupes, magnifiers, and microscopes) within a distance of 100 mm
could pose an eye hazard. Statement 1056
Warning
Class 1 laser product. Statement 1008
Warning
Cisco NCS 2000 series Troubleshooting Guide, Release 11.0
62
General Troubleshooting
Remove SFP or XFP Connectors
