This alarm is demoted by a path label mismatch (PLM) such as LP-PLM.
By default, an HP-ENCAP-MISMATCH alarm causes an ML-Series card data link to go down. This behavior
can be modified using the command-line interface (CLI) command no pos trigger defect encap.
Note
Clear the HP-ENCAP-MISMATCH Alarm
SUMMARY STEPS
1. Ensure that the correct framing mode is in use on the receiving card by completing the following steps:
2. Ensure that the correct framing mode is in use on the transmit card, and that it is identical to the framing
mode used on the receiving card by completing the following steps:
3. If the alarm does not clear, use the ML-Series card CLI to ensure that the remaining settings are correctly
configured:
DETAILED STEPS
Step 1 Ensure that the correct framing mode is in use on the receiving card by completing the following steps:
a) In node view, double-click the ML-Series card to display the card view.
b) Click the Provisioning > Card tabs.
c) In the Mode drop-down list, ensure that the correct mode (GFP-F or HDLC) is selected. If it is not, choose it and
click Apply.
Step 2 Ensure that the correct framing mode is in use on the transmit card, and that it is identical to the framing mode used on
the receiving card by completing the following steps:
a) In node view, double-click the ML-Series card to display the card view.
b) Click the Provisioning > Card tabs.
c) In the Mode drop-down list, ensure that the same mode (GFP-F or HDLC) is selected. If it is not, choose it and click
Apply.
Step 3 If the alarm does not clear, use the ML-Series card CLI to ensure that the remaining settings are correctly configured:
• Encapsulation
• CRC size
• Scrambling state
To open the interface, click the card view IOS tab and click Open IOS Connection.
If the alarm does not get cleared, you need to report a Service-Affecting (SA) problem. Log into the Technical Support
Website at http://www.cisco.com/c/en/us/support/index.html for more information or log into http://www.cisco.com/c/
en/us/support/web/tsd-cisco-worldwide-contacts.html to obtain a directory of toll-free Technical Support numbers for
your country.
Cisco NCS 2000 series Troubleshooting Guide, Release 11.0
229
Alarm Troubleshooting
Clear the HP-ENCAP-MISMATCH Alarm
