Card Behavior
The SDH terminal port loopbacks can either terminate or bridge the signal. TXP terminal loopbacks are
terminated as shown in the following table. During terminal loopbacks, if a port terminates a terminal loopback
signal, the signal only loops back to the originating port and is not transmitted downstream. If the port bridges
a loopback signal, the signal loops back to the originating port and is also transmitted downstream. Client
card terminal loopback bridging and terminating behaviors are listed in the following table.
AIS signal is not injected if the signal is bridged. If the signal is terminated, an applicable AIS is injected
downstream.
Note
Table 2: DWDM Card Terminal Loopback Behavior
Terminal Loopback SignalCard/Port
BridgedTXP_MR_10E/TXP_MR_10E_C/TXP_MR_10E_L client ports
BridgedTXP_MR_10E/TXP_MR_10E_C/TXP_MR_10E_L trunk ports
BridgedTXP_MR_2.5G/TXPP_MR_2.5G client ports
BridgedTXP_MR_2.5G/TXPP_MR_2.5G trunk ports
BridgedMXP_2.5G_10E_C/MXP_2.5G_10E_L client ports
BridgedMXP_2.5G_10E_C/MXP_2.5G_10E_L trunk ports
BridgedMXP_MR_10DME client ports
BridgedMXP_MR_10DME trunk ports
BridgedMXP_MR_2.5G/MXPP_MR_2.5G client ports
BridgedMXP_MR_2.5G/MXPP_MR_2.5G trunk ports
BridgedGE_XP/10GE_XP client ports
BridgedGE_XP/10GE_XP trunk ports
BridgedADM-10G client ports
BridgedADM-10G trunk ports
Bridged40G-MXP-C/40E-MXP-C/40ME-MXP-C client ports
Bridged40G-MXP-C/40E-MXP-C/40ME-MXP-C trunk ports
Bridged40E-TXP-C/40ME-TXP-C client ports
Bridged40E-TXP-C/40ME-TXP-C trunk ports
BridgedAR_XP/AR_MXP client ports
Cisco NCS 2000 series Troubleshooting Guide, Release 11.0
6
General Troubleshooting
Card Behavior
