SECTION6—WHEELBRAKEASSEMBLIES
6
WheelBrakeAssemblies
WARNING
AsbestosDustWarning
•Someaftermarketbrakeshoescontainasbestosber,andasbestosdustiscreatedwhenthesebrake
mechanismsarehandled.Wearapprovedeyeandrespiratoryprotectionwhendisassemblingand
cleaningbrakemechanisms.Inhalationofasbestoscouldresultinseverepersonalinjuryordeath.Do
notusecompressedairoraerosolspraystocleanthebrakemechanism.Cleanbrakemechanism
usingthenegativepressureenclosure/hepavacuumsystemorlowpressure/wetcleaningmethodper
OSHA/29CFR-1910.1001.
GENERALINFORMATION
Thevehicleisequippedwithself-adjusting,mechanically-expandingshoe,drumbrakesoneachrearwheel.
BRAKESHOEREMOVAL
CAUTION
•Wornordamagedbrakedrumscannotbemachinedtorenishthem.Replaceasnecessary.
1.Disablethevehicle.
2.ElectricVehicle:Disconnectthebatteriesanddischargethecontroller.
GasolineVehicle:Disconnectbatteryandsparkplugwire.
3.Loosenthelugnutsontherearwheels.
4.Lifttherearofthevehicle.
WARNING
•Liftonlyoneendofthevehicleatatime.Useasuitableliftingdevice(chainhoistorhydraulicoor
jack)with1000lb.(454kg)minimumliftingcapacity.Donotuseliftingdevicetoholdvehicleinraised
position.Useapprovedjackstandsofproperweightcapacitytosupportthevehicleandchock
thewheelsthatremainontheoor.Whennotperformingatestorserviceprocedurethatrequires
movementofthewheels,lockthebrakes.
5.Removetheoormat.
6.Removethepedalaccesspanel.
2020Precedent,Villager2and4MaintenanceandServiceManualPage6-1

Club Car Precedent Specifications

General

Power Source	Electric
Batteries	Six 8-volt (Electric)
Brakes	Mechanical Drum
Seating Capacity	2
Overall Length	91.5 in
Overall Width	47 in
Range	Up to 30 miles (depending on conditions)
Frame	Aluminum
Suspension	Leaf spring (front and rear)
Tires	18 x 8.5-8
Payload Capacity	800 lb
