Club Car Precedent Maintenance And Service Manual

SECTION5—ACCELERATORANDBRAKEPEDALGROUP
5
AcceleratorandBrakePedalGroup
DANGER
•SeeGeneralWarningsonpage1-2.
WARNING
•SeeGeneralWarningsonpage1-2.
PEDALGROUP–ELECTRICVEHICLE
SeeGeneralWarningsonpage1-2.
PEDALGROUPREMOVAL
1.Disconnectthebatteriesanddischargethecontroller.SeeDisconnecttheBatteries–ElectricVehicles
onpage1-4.
2.Removescrews(1).Pulloormatretainer(3)awayfromthevehicle(Figure5-1,Page5-1).
3.Pulloormat(2)overthepedalgrouptogainaccesstothepedalgrouphardware.
1
2
3
629
Figure5-1PedalGroupAccess
4.Removefastener(10)andliftoffcoverplate(7)(Figure5-2,Page5-2).
5.Loosenjamnuts(4and5)oneachsideofturnbuckle(6).
NOTE:Nut(4)hasaleft-handthread.
6.Loosenturnbuckle(6)untilthethreadedrod(8)fromthepedalgroup(11)isfreeoftheturnbuckle(Figure5-2,
Page5-2).
7.Removetwoscrews(2)onthedriversideofthepedalgroupandtwoscrews(1)onthepassengersideof
thepedalgroup.
8.Disconnectthewireharness(12)fromtheMCOR(13).
9.Liftpedalgroupfromvehicle.
2020Precedent,Villager2and4MaintenanceandServiceManualPage5-1
