PedalGroup–GasolineVehicleACCELERATORANDBRAKEPEDALGROUP
PEDALGROUP–GASOLINEVEHICLE
SeeGeneralWarningsonpage1-2.
PEDALGROUPREMOVAL
1.Disconnectbatteryandsparkplugwire(s).
SeeDisconnecttheBattery-GasolineVehiclesonpage1-3.
2.Removescrews(1).Pulloormatretainer(3)awayfromthevehicle(Figure5-3,Page5-4).
3.Pulloormat(2)overthepedalgrouptogainaccesstothepedalgrouphardware.
4.Removefastener(10)andliftoffcoverplate(7)(Figure5-4,Page5-5).
5.Loosenjamnuts(4and5)oneachsideofturnbuckle(6).
NOTE:Nut(4)hasaleft-handthread.
6.Loosenturnbuckle(6)untilthethreadedrod(8)fromthepedalgroup(11)isfreeoftheturnbuckle(Figure5-4,
Page5-5).
1
2
3
629
Figure5-3PedalGroupAccess
7.Loosentwonuts(9)ontheacceleratorcableandliftthecablefromitsmountingbracket.
8.Removetwoscrews(2)onthedriversideofthepedalgroupandtwoscrews(1)onthepassengersideof
thepedalgroup.
9.Disconnectsix-pinconnector(12)fromthrottlepositionsensor.
10.Releasetheendoftheacceleratorcable(13)fromthepedalgroup.
11.Liftpedalgroupfromvehicle.
Page5-42020Precedent,Villager2and4MaintenanceandServiceManual
