KillLimitSwitch
GASOLINEVEHICLE-ELECTRICAL
COMPONENTS
KILLLIMITSWITCH
SeeGeneralWarningsonpage1-2.
Thekilllimitswitchishousedinsidethethrottlepositionsensor.Thethrottlepositionsensoritselfisnotintendedtobe
replaced.Ifsensorisdeterminedtoneedreplacingthroughtestproceduresfoundinthismanual,theaccelerator
pedalassemblymustbereplaced.
MULTI-PURPOSEBUZZERLIMITSWITCH
SeeGeneralWarningsonpage1-2.
Themulti-purposebuzzerlimitswitchislocatedonthebackoftheForward/Neutral/Reversecontrol(FNR).
Figure19-25Multi-purposeBuzzerLimitSwitch
MULTI-PURPOSEBUZZERLIMITSWITCHREMOVAL
1.Disconnectthebatteryandsparkplugwire.
2.Disconnectthemulti-purposebuzzerlimitswitchwiresfromthemainharness.
3.Removethenuts(1)andwashers(2)(Figure19-25,Page19-24).
4.Removetheneutrallockoutlimitswitch(3)andwashers(4).
5.Removethemulti-purposebuzzerlimitswitch(5).
Page19-242020Precedent,Villager2and4MaintenanceandServiceManual
