Club Car Precedent Maintenance And Service Manual

ELECTRICVEHICLE-ELECTRICAL
COMPONENTSSolenoid
13
5.PlacetheTow/RunswitchintheTOWpositionandconnectthebatteries.SeeConnecttheBatteries–Electric
Vehiclesonpage1-5.
6.PlacetheT ow/RunswitchintheRUNposition.
7.IfvehicleisequippedwiththeGuardianSVCsystem,performthefollowingadditionalstepsforpropersetup.
7.1.ConnectanCDTtotheCDTportonthevehicle.
7.2.SelectProgram,Settings,ControlModeandsetthevalueto1.
7.3.SelectProgram,Settings,AntiTamperandsetthevalueto0.
7.4.SelectProgram,VehicleID,VehicleS/Nandenterthelastsixdigitsofthevehicleserialnumber.
NOTE:Thespeedforscrollingvaluesmaybeincreasedbyutilizingthebookmarkkeys(yellowbuttons)incombination
withthedatainc/deckey(+/-).
7.5.SelectProgram,VehicleID,VehicleDecalandenterthenumberontheVehicleNumberDecal.
7.6.SelectProgram,VehicleID,VehicleDateofManufactureandenterthenumberonthemodelyearand
weekfromthevehicleserialnumber.
7.7.SelectInformation,SoftwareVersionandverifythevalueis13orhigher.Ifnot,contactaClubCar
TechnicalRepresentative.
7.8.PlacetheTow/RunswitchintheTOWpositionfor30seconds.ThenreturnittoRUN.
8.Inspectthevehicleforproperoperation.
WARNING
•MakesurethatthevehicleoperatesintheforwarddirectionwhentheForward/Reverseswitchis
intheFORWARDposition.
•MakesurethatthevehicleoperatesinthereversedirectionwhentheForward/Reverseswitchisinthe
REVERSEposition.ThereversebuzzerwillsoundasawarningwhentheForward/Reverseswitch
isinREVERSE.
•MakesurethatthevehicledoesnotoperatewhentheForward/ReverseswitchisintheNEUTRAL
position.
SOLENOID
SeeGeneralWarningsonpage1-2.
Thesolenoidislocatedontherearsideoftheelectronicsmodule.
TESTINGTHESOLENOID
SeeTestProcedure7–SolenoidActivatingCoilonpage12-20andTestProcedure9–SolenoidContinuityon
page12-21.
SOLENOIDREMOVAL
1.Disconnectthebatteriesanddischargethecontroller(1).SeeDisconnecttheBatteries–ElectricVehicles
onpage1-4.
2.Removetheelectronicsmodulecover(8)toaccessthesolenoid(4).SeeElectronicsModuleCoverRemoval
onpage13-6.
2020Precedent,Villager2and4MaintenanceandServiceManualPage13-13

Club Car Precedent Specifications

General

Power Source	Electric
Batteries	Six 8-volt (Electric)
Brakes	Mechanical Drum
Seating Capacity	2
Overall Length	91.5 in
Overall Width	47 in
Range	Up to 30 miles (depending on conditions)
Frame	Aluminum
Suspension	Leaf spring (front and rear)
Tires	18 x 8.5-8
Payload Capacity	800 lb
