15
ChargerTroubleshootingELECTRICVEHICLE-BATTERYCHARGER
CHARGERTROUBLESHOOTING
SeeGeneralWarningsonpage1-2.
DANGER
•DonottouchanywireorcomponentinthebatterychargerwhileACpowerispresent.Failureto
heedthiswarningwillresultinanelectricshock.
WARNING
•Knowledgeofbatterychargerwiringandcomponentterminologyisrequiredbeforeattemptingany
repair.SeeTheChargeCircuitonpage15-9.
•Priortoservicingtheexternalcharger,disconnecttheDCplugfromthevehiclechargerreceptacle
andtheACpowersupplycordfromthewalloutlet.
•Priortoservicingtheonboardcharger,disconnecttheACpowersupplycordfromthewalloutletand
removethebatterychargerfromthevehicle.SeeOnboardChargerRepairsonpage15-26.
NUMBERINGVEHICLESANDCHARGERS
Returnthevehiclestothesamechargereachnightifpossible.Ifthevehiclesareputinastoragefacilityatrandom
andavehicledieswhileinuseandtestingshowsthebatteriesaresound,thentheproblemismostlikelywiththe
charger.However,ndingtheproblemchargermayprovetobequitetimeconsuming.Numberingthevehiclesand
thechargersandreturningeachvehicletoitsdesignatedchargereachnightcansignicantlyreducetheamount
oftimespenttroubleshootingaproblem.
USBSERVICEPORT
NOTE:ThetriangularchargestatuslightdoublesastheUSBlight.FlashinggreenmeansdatatransferfromtheUSB
isoccurring.Solidgreenmeansdatatransferiscomplete.
UsetheUSBserviceportforchargingalgorithmupdates,softwareupdatesandtroubleshooting.
Tousetheport,pullthecoverfromtheportandinsertaUSBashdrive.
Toupdatecharger:Withupdatelealreadyonashdrive,insertdriveintochargerandletchargerndleand
updateitself.
Todownloadfromcharger:Insertanemptyashdriveintochargerandletchargerwritechargehistoryletoit.
Whennished,reinstallthecover.
INCOMINGACSERVICE
MakesuretheincomingAClineserviceissufcient.Ifcircuitbreakersaretripping,fusesblowduringthenightorthe
chargerdoesnotgivetherequiredstartingratewhensoundbatteriesareputoncharge,anAClineproblemexists.
Theelectricalservicetothevehiclestoragefacilityshouldbesufcienttodeliveradequatevoltageandcurrenttoeach
chargerwithallthechargersturnedon.Ifnot,consultyourlocalpowercompanyorelectricalcontractor.
Page15-142020Precedent,Villager2and4MaintenanceandServiceManual

Club Car Precedent Specifications

General

Power Source	Electric
Batteries	Six 8-volt (Electric)
Brakes	Mechanical Drum
Seating Capacity	2
Overall Length	91.5 in
Overall Width	47 in
Range	Up to 30 miles (depending on conditions)
Frame	Aluminum
Suspension	Leaf spring (front and rear)
Tires	18 x 8.5-8
Payload Capacity	800 lb
