Club Car Precedent Maintenance And Service Manual

SECTION24—GASOLINEVEHICLE-TRANSAXLE
24
GasolineVehicle-Transaxle
DANGER
•SeeGeneralWarningsonpage1-2.
WARNING
•SeeGeneralWarningsonpage1-2.
GENERALINFORMATION
Thevehiclesaddressedinthismanualareequippedwithheavy-dutytransaxles.Thetransaxleutilizesinternalgearing
tochangevehicledirection.Becausethetransaxleisusedtoreversevehicledirection,theengine,driveclutch,belt,
anddrivenclutchrotateinthesamedirection;therefore,theengineandclutchesarenotsubjectedtoreversingloads.
Thisreducesmaintenancerequirementsontheengineandclutches.Withthetransaxle,poweristransferredfromthe
enginethroughthedriveclutch,thedrivebelt,thedrivenclutch,andthenthroughthetransaxletothewheels.
SHIFTERLEVER
Ashifterlever,connectedtoashifterarm,isusedtochangethegearstooneofthreeshiftpositions:forward(F),
neutral(N),orreverse(R).BringthevehicletoacompletestopbeforechangingForRdirection.
MAINTENANCE/OPERATESWITCH
WARNING
•WiththeswitchintheMAINTENANCEpositionandtheenginerunning,thevehiclemaymovesuddenly
iftheForward/Neutral/Reversehandleisshiftedoraccidentallybumped.Topreventthis,chockthe
frontandrearwheelsandrmlysettheparkbrakebeforeservicingorleavingthevehicle.
81
Figure24-1MAINTENANCE/OPERATESwitch
Themaintenance/operateswitchisusedbyatrainedtechniciantodocertainmaintenancefunctionswiththeengineon.
NOTE:MakesurethattheMaintenance/OperateswitchissettoOPERATEafterthevehicleisserviced.
2020Precedent,Villager2and4MaintenanceandServiceManualPage24-1
