ELECTRICVEHICLE-BATTERYCHARGERGeneralInformation
15
chargealgorithmthatisappropriatetothespecicbatterytypeusedinthevehicle.Whenthechargerisconnected,
thereisa2to5seconddelaybeforechargingbegins.WhentheACcordisconnected,thechargerperformsastart-up
self-test(allthreechargerstatusindicatorsonthefrontofthechargerashONatthesametime).
Thechargersuppliedwiththeelectricvehicleresolvesthemostcommonproblemsassociatedwithbatterycharging.
Thechargerutilizessophisticatedchargeterminationcriteriontoshutoffautomatically,preventingthepossibilityof
eitherunderchargingorovercharging.Thechargeraccomplishesthisbymonitoringbatteryvoltage,chargecurrent,
chargetimeandusingstrictdV/dtterminationcriterion.
Batteriesshouldneverbeleftinadischargedstate,asthistooaffectstheinternalcomponentsandcanreducethe
capacityofthebattery.Thebatteriesshouldbechargedeverydaytheyareused.However,thebatteriesshould
notbechargediftheyhavenotbeenused.
USBSERVICEPORT
TheERICchargerhasaUSBportforusebyClubCarauthorizedtechniciansfordatatransfer,reconguration,
andupdates.KeeptheUSBportcoverinplacewhentheportisnotinuse.SeeUSBServicePortCleaning
andCareonpage15-13.
ULANDCSALISTING
High-frequencychargingsystembatterychargershavebeenlistedbyULandbytheCanadianUnderwritersand
meetthecriteriaoftheCanadianStandardsAssociation.
CECOMPLIANCE
ThisbatterychargeriscompliantwiththeEUEMCDirective2004/108/EC.
PLUGANDRECEPTACLE
Thechargercord,plug,andreceptaclearewearitemsandshouldbeinspecteddaily.Visuallyinspectforcracks,
looseconnections,frayedwiringorbentpins;theymustbeimmediatelyreplacedwhenwornordamaged.Donot
attempttostraightenabentpin.Ifchargerplugorreceptacleshowsignsofcorrosionortheplugisdifculttoinsert
orremove,checkforbentpins,thencleanthereceptaclecontactsandplugterminalswithagoodelectricalcontact
cleanerorlightcoatingofWD-40
®
brandspraylubricant.Theplugshouldthenbeinsertedandremovedseveraltimes
toensureeaseofinsertion,easeofremoval,andgoodelectricalcontact.
DANGER
•Topreventre,immediatelyreplacebatterychargerDCcordplugandreceptacleifthefollowing
conditionsexist:
–Plugpinshavewornnickelplatingandcopperisexposed.
–Plugrequiresaninordinateamountofforcetoinsertintoreceptacle,especiallyifaccompanied
bya“grinding”feel.
WARNING
•Ifpinsarebent,theplugmustbereplacedimmediately.Theplugisnotserviceable.Donotattemptto
repairtheplugorstraightenbentpins.
•DisconnecttheACcordpriortolubricatingtheplugandreceptacle.
NOTE:IfthewarningtaghasbeendamagedorremovedfromtheDCcord,haveitreplacedimmediately.
2020Precedent,Villager2and4MaintenanceandServiceManualPage15-3

Club Car Precedent Specifications

General

Power Source	Electric
Batteries	Six 8-volt (Electric)
Brakes	Mechanical Drum
Seating Capacity	2
Overall Length	91.5 in
Overall Width	47 in
Range	Up to 30 miles (depending on conditions)
Frame	Aluminum
Suspension	Leaf spring (front and rear)
Tires	18 x 8.5-8
Payload Capacity	800 lb
