Club Car Precedent Maintenance And Service Manual

19
USBReceptacle
GASOLINEVEHICLE-ELECTRICAL
COMPONENTS
USBRECEPTACLE
The5-volt,2.1ampUSBreceptaclesupplieselectricitytopowerandchargeportabledevices.TheUSBreceptacleis
notformovementofdata.
TheUSBreceptaclewillonlyoperatewhenashieldedUSBcordisconnected.WhentheUSBreceptacleisnotinuse,
removetheshieldedUSBcordtopreventbatterydrain.
USBRECEPTACLEREMOVAL
1.Disconnectthebatteryandsparkplugwire.
2.Removetheinstrumentpanel.
3.DisconnecttheUSBreceptaclewires(1and2)fromtheinstrumentpanelwires(Figure19-40,Page19-36).
Figure19-40USBReceptacle
4.DisconnecttheUSBreceptaclewires(3and4)fromthekeyswitch.
5.Pushthelocktabs(5)onbothsidesandremovetheUSBreceptacle(6).
USBRECEPTACLEINSTALLATION
1.PuttheUSBreceptaclewiresintothedash.
2.PushtheUSBreceptacle(6)intothedash(Figure19-40,Page19-36).
3.Makesurethatthelockingtabs(5)engage.
4.ConnecttheredinstrumentpanelwiretotheredUSBreceptaclewire(1).
5.ConnecttheblackinstrumentpanelwiretotheblackUSBreceptaclewire(2).
6.ConnecttheredUSBreceptaclewire(3)tokeyswitch2terminal.
7.ConnecttheblackUSBreceptaclewire(4)tokeyswitchM-terminal.
8.Installtheinstrumentpanel.
9.Connectthebatteryandsparkplugwire.
Page19-362020Precedent,Villager2and4MaintenanceandServiceManual

Club Car Precedent Specifications

General

Power Source	Electric
Batteries	Six 8-volt (Electric)
Brakes	Mechanical Drum
Seating Capacity	2
Overall Length	91.5 in
Overall Width	47 in
Range	Up to 30 miles (depending on conditions)
Frame	Aluminum
Suspension	Leaf spring (front and rear)
Tires	18 x 8.5-8
Payload Capacity	800 lb
