Club Car Precedent Maintenance And Service Manual

4
Two-Passenger-RearBodyBODYANDTRIM
REARBEAUTYPANEL
Two-passengerrearbeautypanelprocedures.
3
2
1
2
5
4
6
Figure4-30RearBeautyPanel
RearBeautyPanelRemoval
1.Removethestructuralaccessorymodule(SAM).
2.Removethescrews(1)(Figure4-30).
3.Removethecanopysupportbrackets(2).
4.Removethefourscrews(3).
5.RemovetheForward/Neutral/Reversecontrol(FNR).
6.Disengagethetwobodyclips(4)oftherearbeautypanel(5)fromtheslotsintherearunderbody(6).
7.Removetherearbeautypanelfromvehicle.
RearBeautyPanelInstallation
1.Installtherearbeautypanel(5)ontovehicle(Figure4-30).
2.Makesurethatthetwobodyclips(4)engagetheslotsintherearunderbody(6).
3.Installthefourscrews(3).Tightenthescrewsto44lb·in(5N·m).
4.InstalltheForward/Neutral/Reversecontrol(FNR).
5.Putthecanopysupportbrackets(2)onthevehicle.
6.Installthescrew(1).Tightenthescrewto53lb·in(6N·m).
Page4-342020Precedent,Villager2and4MaintenanceandServiceManual
