Club Car Precedent Maintenance And Service Manual

ELECTRICVEHICLE-ELECTRICAL
COMPONENTSForward/ReverseRockerSwitch
13
2
2
1
3
4
5
6
705
Figure13-7Forward/ReverseRockerSwitch
FORWARD/REVERSEROCKERSWITCHINSTALLATION
1.Routethethreewiresthroughbezel.Connecttheblue(4),orange(5)andbrown(6)wirestotherockerswitch
(3),exactlyasshownin(Figure13-7,Page13-5).
2.Orienttherockerswitch(3)sotheterminalsaretowardsthefrontofthehousing(1).Pushrockerswitch(3)
intohousing(1).
3.Placethehousinginpositiononthebodyandinstallthetwoscrews(2).Tightento20in·lb(2.3N·m).
4.PlacetheTow/RunswitchintheTOWpositionandconnectthebatteries.SeeConnecttheBatteries–Electric
Vehiclesonpage1-5.
5.PlacetheT ow/RunswitchintheRUNposition.
6.Inspectthevehicleforproperoperation.
WARNING
•MakesurethatthevehicleoperatesintheforwarddirectionwhentheForward/Reverseswitchis
intheFORWARDposition.
•MakesurethatthevehicleoperatesinthereversedirectionwhentheForward/Reverseswitchisinthe
REVERSEposition.ThereversebuzzerwillsoundasawarningwhentheForward/Reverseswitch
isinREVERSE.
•MakesurethatthevehicledoesnotoperatewhentheForward/ReverseswitchisintheNEUTRAL
position.
2020Precedent,Villager2and4MaintenanceandServiceManualPage13-5

Club Car Precedent Specifications

General

Power Source	Electric
Batteries	Six 8-volt (Electric)
Brakes	Mechanical Drum
Seating Capacity	2
Overall Length	91.5 in
Overall Width	47 in
Range	Up to 30 miles (depending on conditions)
Frame	Aluminum
Suspension	Leaf spring (front and rear)
Tires	18 x 8.5-8
Payload Capacity	800 lb
