Club Car Precedent Maintenance And Service Manual

GASOLINEVEHICLE-ELECTRICAL
COMPONENTSFuelGauge/HourMeter
19
4.Removethescrews(2).
5.Removethebrakelightrelay.
BRAKELIGHTRELAYINSTALLATION
1.Installthebrakelightrelay(1)ontheinstrumentpanel(Figure19-31,Page19-28).
2.Installthescrews(2).
3.Connectthewirestothebrakelightrelayterminals(Figure19-32,Page19-29).
PinDescriptionWireColor
1Blue
2Red
4Black
6Green
Figure19-32BrakeLightRelayTerminals
4.Installtheinstrumentpanel.
5.Connectthebatteryandsparkplugwire.
FUELGAUGE/HOURMETER
GENERALINFORMATION
WiththekeyswitchintheOFFposition,thefuelgaugeeldisblank;however,thehourmetereldisalwaysON.
WhenthekeyswitchisturnedtoON,thefuelgaugeeldactivates.Thefuelgaugeinitiallyregistersfullbefore
indicatingtheactualfuellevel.
Thehourmeterdisplaysthenumberofhoursofuseinincrementsof0.1(onetenth)hour,butdoesnotrecord
additionaltimeunlessthekeyswitchisintheONpositionandtheengineison.Whenrecording,thehourglassicon
ontheleftblinks.
2020Precedent,Villager2and4MaintenanceandServiceManualPage19-29

Club Car Precedent Specifications

General

Power Source	Electric
Batteries	Six 8-volt (Electric)
Brakes	Mechanical Drum
Seating Capacity	2
Overall Length	91.5 in
Overall Width	47 in
Range	Up to 30 miles (depending on conditions)
Frame	Aluminum
Suspension	Leaf spring (front and rear)
Tires	18 x 8.5-8
Payload Capacity	800 lb
