Club Car Precedent Maintenance And Service Manual

24
RearHubsGASOLINEVEHICLE-TRANSAXLE
REARHUBS
REARHUBREMOVAL
1.TurnthekeyswitchtotheOFFpositionandremovethekey,andplacetheForward/Neutral/Reversehandlein
theNEUTRALposition.
2.Disconnectbatteryandsparkplugwire.SeeDisconnecttheBattery-GasolineVehiclesonpage1-3.
3.Placechocksatthefrontwheelsandloosenlugnutsonbothrearwheels.
4.Removetherubberdustcap(1).
5.Removeanddiscardthecotterpin(2)(Figure24-3,Page24-4).
6.Removenutlockingcap(3)andloosenthehubnut(4)ontheaxleshaft.
7.Liftandsupporttherearofvehicle.
8.Removethelugnutsandwheel.
9.Slidebrakedrumoffhub.
10.Removehubnut(4)andlargeatwasher(5)andpullhub(6)offaxleshaft.SeefollowingNOTE.
NOTE:Ifthehub(6)doesnotslideeasilyofftheaxleshaft,useatwoorfour-jawwheelpullertoremovethehub.
6
1
3
4
5
2
3056
Figure24-3RearHubExplodedView
REARHUBINSTALLATION
1.Inspectbrakeshoesforwearandreplaceifnecessary.SeeWheelBrakeAssembliessection.
NOTE:Ifbrakeshoesarereplacedononeside,replacetheoppositesidealso.
2.Cleanthesplinesandthreadedportionoftheaxleshaft.
3.Applyanti-seizecompoundtoboththeaxleshaftsplinesandhub(6)splines.SeefollowingCAUTION.
Page24-42020Precedent,Villager2and4MaintenanceandServiceManual
