ELECTRICVEHICLE-BATTERYCHARGERExternalChargerRepairs
15
EXTERNALCHARGERREPAIRS
SeeGeneralWarningsonpage1-2.
WARNING
•Knowledgeofbatterychargerwiringandcomponentterminologyisrequiredbeforeattemptingany
repair(Figure15-6,Page15-9).
•Priortoservicingthecharger,disconnecttheDCplugfromthevehiclechargerreceptacleandthe
ACcordfromtheACoutlet.
NOTE:Thischargerhasnointernalstoserviceorrepair.Itonlyhasafewexternalrepairsthatcanbeperformed.
Ifaninternalcomponentneedsrepair,thechargermustbereplaced.
2
1
8
9
5
10
6
4
7
3
11
2790
Figure15-10ExternalHigh-FrequencyChargerComponents
TERMINALBLOCKCOVERREMOVAL
1.DisconnectDCcord(1)fromvehicle.
2.DisconnectACcord(2)fromACoutlet.
3.Pushinmountingtabs(Figure15-11,Page15-24)toreleasecover(3)fromterminalblock(4).
2020Precedent,Villager2and4MaintenanceandServiceManualPage15-23
