Club Car Precedent Maintenance And Service Manual

13
ElectronicsModuleCover
ELECTRICVEHICLE-ELECTRICAL
COMPONENTS
ELECTRONICSMODULECOVER
SeeGeneralWarningsonpage1-2.
Theelectronicsmodulecoverneedstoberemovedtogainaccesstothespeedcontroller,T ow/Runswitch,and
solenoid.
ELECTRONICSMODULECOVERREMOVAL
1.Disconnectthebatteriesanddischargethecontroller.SeeDisconnecttheBatteries–ElectricVehicles
onpage1-4.
2.Removethetwoplasticrivets(1)thatsecuretheaccesspanel(2)tothevehicle(Figure13-8,Page13-7).
3.Removecover(5)byrstreleasingthefourtabs(3)fromthematchingholesinthehoodofthebatterybucket.
Then,maneuverthecovertoreleasethetwohooks(4)thatsecurethecovertothebatterybucket.
CAUTION
•Becarefulnottobreakthetwohooks(4)onthebottomofthecover.Pushthebottomofthecoverup
toreleasethehooksbeforepullingcoverawayfrombatterybucket.
ELECTRONICSMODULECOVERINSTALLATION
1.Installcover(5)byrsthookingthefourtabs(3)intothematchingholesinthehoodofthebatterybucket(Figure
13-8,Page13-7).Then,usethetwohooks(4)tosecurethecovertothebatterybucket.
2.Placeaccesspanel(2)onvehicleandsecurewiththetwoplasticrivets(1).SeefollowingCAUTION.
CAUTION
•Exposuretowatermaydamageelectroniccomponents.
–Donotoperatevehiclewithoutthiscoverproperlyinstalled.
–Donotdirectwaterstreamintheareaofthecover.
3.PlacetheTow/RunswitchintheTOWpositionandconnectthebatteries.SeeConnecttheBatteries–Electric
Vehiclesonpage1-5.
Page13-62020Precedent,Villager2and4MaintenanceandServiceManual

Club Car Precedent Specifications

General

Power Source	Electric
Batteries	Six 8-volt (Electric)
Brakes	Mechanical Drum
Seating Capacity	2
Overall Length	91.5 in
Overall Width	47 in
Range	Up to 30 miles (depending on conditions)
Frame	Aluminum
Suspension	Leaf spring (front and rear)
Tires	18 x 8.5-8
Payload Capacity	800 lb
