Club Car Precedent Maintenance And Service Manual

GASOLINEVEHICLE-ELECTRICAL
COMPONENTSHeadlightSwitch
19
2.Fuel(+)Blue
4.FuelInputOrange
6.Hour(-)Black/White
7.HourInputRed
480
Figure19-34FuelGauge/HourMeter
4.Installtheinstrumentpanel.
5.Connectthebatteryandsparkplugwire.
HEADLIGHTSWITCH
Figure19-35HeadlightSwitch
HEADLIGHTSWITCHREMOVAL
1.Disconnectthebatteryandsparkplugwire.
2.Removetheinstrumentpanel.
3.Disconnectthewiresfromtheheadlightswitch(1)(Figure19-35,Page19-31).
4.Loosenthesetscrew(2).
5.Removethethreadedknob(3).
6.Removethenut(4).
7.Removetheheadlightswitchandnut(5).
HEADLIGHTSWITCHINSTALLATION
1.Installthenut(5)ontotheheadlightswitch(1)(Figure19-35,Page19-31).
2.Installtheheadlightswitchintotheinstrumentpanel.
3.Installthenut(4).Tightenthenutto2.2lb·in(0.25N·m).
4.Tightenthenut(5).
5.Installthethreadedknob(3).
6.Tightenthesetscrew(2).
2020Precedent,Villager2and4MaintenanceandServiceManualPage19-31
