24
GeneralInformationGASOLINEVEHICLE-TRANSAXLE
_
POSITIONDESCRIPTION
OPERATE
NormalOperation
Theenginewillnotoperateinneutral.
MAINTENANCE
Theenginewilloperateinneutral(N).
Thevehiclewillnotoperateintheforward
(F)orreverse(R)position.
GOVERNORSYSTEM
Thegovernorsystemregulatesvehiclegroundspeed.Itismountedinsidethetransaxleandisdrivenbytransaxle
gears.Ifanyofthegovernorlinkagesareremovedinordertoserviceothercomponents,readjustmentofthegovernor
linkageisrequired.SeeGovernorCableInstallationandAdjustmentonpage21-3.
TRANSAXLESERVICE
Thetransaxleisextremelydurableandshouldrequireverylittleserviceundernormaloperatingconditions.Theonly
servicerequiredistomaintainproperlubricantlevel.SeeLubricationonpage24-2.Undernormaloperating
conditions,adjustmenttothesystemshouldnotberequired.
LUBRICATION
Therearetwooilportplugslocatedontheright(drivenclutch)sideofthetransaxle(Figure24-2,Page24-3).When
thevehicleisonalevelsurface,usetheupperplugasalubricantlevelindicator.Lubricantlevelshouldbeevenwith
thebottomoflevelindicatorhole.Usethelowerplugfordraining.
OilChange–Transaxle
1.Whendrainingtransaxleoil,removebothplugstoallowtheoiltodrainfaster.
2.Cleanandreinstallthedrainplugandgasketbeforellingthetransaxlewithnewlubricant.Tightendrainplugto
17lb·ft(23N·m).
3.Useafunnelwhenllingthetransaxlethroughthelubricantlevelindicatorhole.Fillwith67.6-oz(2L)80-90
WT.APIclassGLor80-90WT.AGMAclass5EPgearlubricant(oruntillubricantbeginstorunoutofthe
levelindicatorhole).
4.Installupperplugandgasketandtightento17lb·ft(23N·m).
Page24-22020Precedent,Villager2and4MaintenanceandServiceManual

Club Car Precedent Specifications

General

Power Source	Electric
Batteries	Six 8-volt (Electric)
Brakes	Mechanical Drum
Seating Capacity	2
Overall Length	91.5 in
Overall Width	47 in
Range	Up to 30 miles (depending on conditions)
Frame	Aluminum
Suspension	Leaf spring (front and rear)
Tires	18 x 8.5-8
Payload Capacity	800 lb
