RackandPinionSTEERINGANDFRONTSUSPENSION
RACKANDPINION
CAUTION
•Frontimpactsthatbendtierodsand/ordraglinkscanpossiblydamageinternalsteeringgear
components.Themanufacturerrecommendsinspectingtherackandpinionandreplacingifdamaged.
RACKANDPINIONINSPECTION
1.Lookforobviousdamagetothechassis,wheretherackandpinionismounted,andtherackandpinionhousing.
Particularlycheckthehousingforbrokenmountingpoints.
2.Comparethetoe-inagainstthespecication.SeeTow-inAdjustment.
3.Ifobviousvisibledamageisfound,suchasabenttierod,checkthesteeringgearforabnormalfree-play,noise,
bindingorclunkingwhileitisunderaload.Withthesteeringsystemfullyassembledandallfourtiresonthe
ground/oor,turnthesteeringwheelfromstoptostop.Whileturning,feelforanybinding,clunkingortight/loose
spots.Listenforunusualnoises.Replacetherackandpinionasanassemblyifanyisfound.
4.Intheeventofanknownimpactandobviousvisibledamageisnotfoundinthemethoddescribedabove,
disconnectthetierodsand/ordraglinksfromthespindles.Turnthesteeringwheelfromstoptostop.While
turning,feelforanybindingortight/loosespots.Listenforunusualnoises.Replacetherackandpinionasan
assemblyifanyisfound.
RACKANDPINIONREMOVAL
1
4
3
6
2
5
7
1383B
Figure7-6RackandPinionRemoval
1.Disablethevehicle.
2.ElectricVehicle:Disconnectthebatteriesanddischargethecontroller.
GasolineVehicle:Disconnectthebatteryandsparkplugwire.
Page7-62020Precedent,Villager2and4MaintenanceandServiceManual
