ShifterCableGASOLINEVEHICLE-TRANSAXLE
3.Pushthecableendsocket(1)offthestud(3)ontheForward/Neutral/Reverseshifterhandle(Figure24-15,
Page24-14).
4.Pressintangs(4)anchoringshiftercable(2)tochassisandpushoutofmountinghole.
5.Loosenjamnuts(1)securingshiftercable(2)toFNR/acceleratorcablebracket(3)(Figure24-16,Page24-14).
Then,removebowtieclip(3)todisconnectshiftercableend(4)fromtransaxleshiftlever(5).
6.Cutwiretiessecuringshiftercabletochassis.
7.Makenoteofcablerouting,thenremoveshiftercablefromvehicle.
2
3
1
4
4
2
3
5
1
3064
Figure24-15ShifterCableatFNRHandle
3133
Figure24-16ShifterCableatTransaxle
SHIFTERCABLEINSTALLATION
1.Installshiftercable(2),routingitexactlyasitwasoriginally,fromForward/Neutral/Reverseshifterhandle
totransaxle.
2.Placerearofcable(2)inFNR/acceleratorcablebracketwithajamnut(1)oneachsideofbracket(Figure24-16,
Page24-14).Tightenjamnuts(1)to22lb·ft(29.8N·m).
3.Hookshiftercableend(4)intotransaxleshiftlever(5)andsecurewithbowtieclip(3).
4.Feedfrontofcable(2)throughitsmountingholeandpushtheplasticanchorintoholeuntiltangs(4)snap
intoplace(Figure24-15,Page24-14).
5.Snapcableendsocket(1)ontostud(3)ofForward/Neutral/Reverseshifterhandle.
6.Secureshiftercablealongchassiswithwiretiesifrequired.
7.Connectbatteryandsparkplugwire.
SeeConnecttheBattery-GasolineVehiclesonpage1-4.
SHIFTERCABLEADJUSTMENT
CableisproperlyadjustedwhenboththeForward/Neutral/Reversehandleandshiftleverontransaxleareinthe
NEUTRALpositionatthesametime.
Page24-142020Precedent,Villager2and4MaintenanceandServiceManual
