Club Car Precedent Maintenance And Service Manual

11
MonitorMenuCONTROLLERDIAGNOSTICTOOL(CDT)
SincetheMonitormenuisupdatedwhilethevehicleisinoperation,thetrainedtechnicianhastheabilitytomonitor
thestatusofseveralcomponentsinconditionsorlocationswhereaproblemwithvehicleperformancehasbeen
reported.SeefollowingWARNING.
WARNING
•Thevehicleoperatorshouldnotmonitorthehandsetwhilethevehicleisinmotion.Atechnician
canmonitorthehandsetwhiletravelingasapassengerinthevehicle.Failuretoheedthiswarning
couldresultinseverepersonalinjuryordeath.
ThefollowingparameterscanbemonitoredinrealtimewiththehandsetfromtheMonitormenu:
BATTVOLTAGE
Displaysthecurrentbatteryvoltageatthespeedcontroller.
V
MIN
I
Displaysvolts(minimum)atacertainamperage.ThisisasettingparameterusedwiththeLowSOC(Stateof
Charge)detectionfault.
SIGNEDBATTERYCURRENT
Whiledrivingthevehicle,thisdisplayseitherthecurrentbeingpulledoutofthebatteriesorthecurrentbeingreturned
tothebatteriesduringregenerativemotorbraking.Ithasarangefromnegative(–)300ampstopositive(+)300amps.
BDIPERCENT
BatteryDischargeIndicator(BDI)Percentdisplaysthecurrentbatterystateofchargeasapercent.Itisbasedon
severalparametersmonitoredbythecontroller.
SPEED
Vehiclespeedinmph.
THROTTLE
Indicatesthepositionoftheacceleratorpedalfrom0%(pedalnotpressed)between95and100%(pedalfullypressed).
ThisitemcanbemonitoredwhenthekeyswitchisintheONorOFFposition.
TEMPERATURE
Displaysthetemperature(indegreesCelsius)ofthespeedcontrollerheatsink.Duringnormaloperatingconditions,the
heatsinktemperatureshouldbebelow185°F(±9)(85°C(±5)).SeefollowingNOTE.
NOTE:Anythingthataddsresistance(i.e.improperbrakeadjustment,lowairpressureintires,lowbatteryvoltage,
etc.)cancausetheoperatingcurrenttobehigherthannormal.Thishighercurrentincreasesthetemperature
ofthespeedcontrollerheatsink.
ARMCURRENT
Displaysthemotorarmaturecurrent(inamperes).
FIELDCURRENT
Displaysthemotoreldcurrent(inamperes).
Page11-102020Precedent,Villager2and4MaintenanceandServiceManual

Club Car Precedent Specifications

General

Power Source	Electric
Batteries	Six 8-volt (Electric)
Brakes	Mechanical Drum
Seating Capacity	2
Overall Length	91.5 in
Overall Width	47 in
Range	Up to 30 miles (depending on conditions)
Frame	Aluminum
Suspension	Leaf spring (front and rear)
Tires	18 x 8.5-8
Payload Capacity	800 lb
