PanhardandBracketREARSUSPENSION
PANHARDANDBRACKET
Figure9-4PanhardandBracket
PANHARDANDBRACKETREMOVAL
1.Disablethevehicle.
2.ElectricVehicle:Disconnectthebatteriesanddischargethecontroller.
GasolineVehicle:Disconnectbatteryandsparkplugwire.
3.Removethebolts(1)(Figure9-4,Page9-4).
4.Removethepanhard(2).
5.Removethebolts(3)andnuts(4).
6.Removethebracket(5).
PANHARDANDBRACKETINSTALLATION
1.Putthebracket(5)intopositionontheframe(Figure9-4,Page9-4).
2.Installthebolts(3)andnuts(4).Tightentheboltsto18.5lb·ft(25N·m).
3.Putthepanhard(2)intopositiononthevehicle.
4.Installthebolts(1).Tightentheboltsto92lb·ft(125N·m).
5.ElectricVehicle:Connectthebatteries.
GasolineVehicle:Connectbatteryandsparkplugwire.
Page9-42020Precedent,Villager2and4MaintenanceandServiceManual
