Club Car Precedent Maintenance And Service Manual

19
Starter/Generator
GASOLINEVEHICLE-ELECTRICAL
COMPONENTS
0
1
1/2
1/2
Figure19-3InspectBrushesandMeasureLength
BRUSHSPRINGINSPECTIONANDREPLACEMENT
1.Visuallyinspectsprings.Replaceallfourspringsifanyspringisdiscoloredfromheat(straworbluishincolor).
2.Installthefourbrushes(27)intotheirholdersandinsertthefourbrushsprings(28)(Figure19-2,Page19-5).
Usingaspringscale,testbrushspringtension.Ifanyspringhasatensionlessthan24ozf(0.68kgf),replaceall
foursprings(Figure19-4,Page19-6).SeefollowingCAUTION.
CAUTION
•Whencheckingbrushspringtension,donotpushspringsbeyondthepointtheywouldnormallybeif
therewerenewbrushesinstalled.Exertingexcessiveforceorpushingbrushspringsbeyondtheir
normalmaximumextensionpointwilldamagesprings.
0
5
10
15
20
25
30
35
40
45
50
490
Figure19-4BrushSpringTensionTest
STARTER/GENERATORASSEMBLY
1.Installthebrushes(27)intotheholders.Installtheterminalhardware(25)(Figure19-2,Page19-5).
Page19-62020Precedent,Villager2and4MaintenanceandServiceManual
