FuelGauge/HourMeter
GASOLINEVEHICLE-ELECTRICAL
COMPONENTS
Figure19-33FuelGauge/HourMeter
FUELGAUGE/HOURMETERREMOVAL
1.Disconnectthebatteryandsparkplugwire.
2.Removetheinstrumentpanel.
3.Disconnectthewiresfromthefuelgauge/hourmeter(1)(Figure19-33,Page19-30).Donotallowwirestotouch.
4.Alternatepullingtheloweranduppertabsawayfromthegaugehousing(2)toremoveclip.
5.Removethefuelgauge/hourmeterfromtheinstrumentpanel.
FUELGAUGE/HOURMETERINSTALLATION
1.Installthefuelgauge/hourmeter(1)intotheholeintheinstrumentpaneluntiltheangeseatsagainstthe
instrumentpanel(Figure19-33,Page19-30).
2.Installthegaugehousing(2).
3.Connectthewirestothefuelgauge/hourmeter(Figure19-34,Page19-30).
PinDescriptionWireColor
1.Fuel(-)
Black
Page19-302020Precedent,Villager2and4MaintenanceandServiceManual
