FrontSuspensionComponentsSTEERINGANDFRONTSUSPENSION
4.Removethebolts(1)fromthebottomofeachkingpin(2)(Figure7-15).
2
1
5
7
6
4
3
1312B
Figure7-15LeafSpringRemoval
5.Removethefourbolts(3)andbottomspringplate(4).
6.Removeleafspring(5).
7.Checktheconditionoftheurethanebushings(6)andsteelsleeves(7).Replaceanythatarewornordamaged.
LEAFSPRINGINSTALLATION
1.Installtheurethanebushings(6)andsteelsleeves(7)intoleafspringeyes(Figure7-16).
2
1
5
7
6
4
3
1312B
Figure7-16LeafSpringInstallation
2.Installtheleafspring(5),bottomspringplate(4),andfourbolts(3).Tightentheboltsinacrisscrosspatternto
37lb·ft(50N·m).
3.Installthekingpins(2)ontheleafspringwiththebolts(1).Tightentheboltsto30lb·ft(41N·m).
4.Installthefrontwheels.
5.Adjustthecamberandtoe-in.
6.ElectricVehicle:Connectthebatteries.
GasolineVehicle:Connectthebatteryandsparkplugwire.
Page7-142020Precedent,Villager2and4MaintenanceandServiceManual

Club Car Precedent Specifications

General

Power Source	Electric
Batteries	Six 8-volt (Electric)
Brakes	Mechanical Drum
Seating Capacity	2
Overall Length	91.5 in
Overall Width	47 in
Range	Up to 30 miles (depending on conditions)
Frame	Aluminum
Suspension	Leaf spring (front and rear)
Tires	18 x 8.5-8
Payload Capacity	800 lb
